Icon Rigid

About the System

Icon Rigid utilises stringers to create a robust rigid grid under structure. This system allows the use of access flooring in environments that have requirements for higher underfloor void spaces, heavier live loads and/or prefinished panels through integration with the Concept + Series.

Load Tolerances

Icon Data Load Tolerance

Explore the relevant tabs below for more information about the system.

Icon Data

Defence Projects

Projects with higher void areas than 800mm high

Courtrooms

Data rooms incorporating the Icon + Series

Tiered seating environments

Cleanrooms incorporating the Icon + Series

4 corner screw panel

Stringered understructure provides rigidity and air tightness

Heavy duty options available

Robust system for high load and specialty applications

Pedestal Features

Adjusting and locking nut, Locating gasket, Sound Impact Buffer, Inbuilt expansion joint gasket.

Locating gasket on pedestal heads for efficient installation

Patented panel design with inbuilt expansion joint and acoustic cutout

High end specialty applications

Ability to withstand heavy load and high traffic areas

Case Study – RAAF Base Williamtown

Security is one of the most important human needs and one of the main factors in Defence building design. Passive defence design focuses on reducing or eliminating the vulnerability, controlling the consequences of invasion and increasing the repairability in the case of an enemy’s surprising attack.

Lend Lease completed a recent 1.5 billion dollar upgrade to the RAAF Base in Williamtown, which employed many passive defence design elements. This high security project included some security design elements that required integration with the access flooring system.

ASP Access Floor’s Icon Rigid System provided the solution to regular lifting of the 10,000m2 of access floor for security scans and sweeps. The rigid grid understructure allows panels to be lifted and replaced on a regular basis with ease, and creates no disruption to the grid layout.
