Icon Air

About the system

Icon Air is specifically designed for environments using an underfloor HVAC (heating, ventilation, and air conditioning) system.

This system incorporates the use of a clip on air tight stringer which creates a seal in between the panels to control and minimize air leakage. With the stringer seal, the underfloor cavity then converts into an air plenum.

Applications

Commercial Office Buildings

Banks

Libraries

Casinos

Icon Air

Specification sheets for CISCA and PSA MOB standards are available upon request >


4 corner screw panel

Stringered understructure provides air tightness

Pedestal Features

Adjusting and locking nut, Locating gasket, Sound Impact Buffer, Inbuilt expansion joint gasket.

Patented panel design with inbuilt expansion joint and acoustic cutout

Zone baffles can be quickly and efficiently installed

Can accommodate underfloor HVAC services and accessories

Clip on stringer allows for fast air tight installation

Locating gasket on pedestal heads for efficient installation


Load tolerances

Icon Air Load Tolerance

Case Study – Medibank

Medibank is one of Australia’s largest health providers whose company’s core value is to provide better health for everyone. This value drove the design of their head office, Medibank Place, where with Brookfield Multiplex they were able to create one of the healthiest workplace’s in the world.

Being able to incorporate under floor air-conditioning in the design of the 46,000m2 of access flooring was an important component of this Green Star project, as it amplifies occupant comfort whilst reducing the systems energy consumption.

The ASP Access Floors Icon Air System complete with its clip on air tight stringer and accessories, including baffling and bridging stringers, guaranteed that the flooring system achieved the required air leakage rates. ASP achieved independent testing and certification of the systems compliance with the BSRIA guide.

Working with Brookfield Multiplex and Medibank on this benchmark project, along with ASP’s airtight patented products, research, development and extensive testing have made ASP the access floor specialists in air tight access floor applications.
