Introducing the Urban Panel
The Urban Series allows for both functionality and design flexibility with its strength and composition.
The steel wrapped Urban Panel is a composition panel with its main core ingredients of gypsum and fibre. The core is wrapped with galvanized steel, creating a strong durable panel suitable for commercial environments.
Explore the Urban Access Floor Systems
Outstanding static and live load performance
Steel encased core adding strength and durability
Non-combustible
Moisture resistant
Ease of maintenance and serviceability with interchangeable panels
Great durability and lifespan contributing to a significant reduction in life cycle costs
Excellent earthing continuity
High recycled content
Contributes significantly to Green Star and LEED requirements through a completed product LCA & EPD
Creates a quiet and comfortable underfoot solution
The Panel Construction
SIZE 600mm x 600mm
DEPTH 33mm
CONSTRUCTION
The panels consist of a hardened steel top and bottom sheet plate with corrosion resistant protection, inside and out, encapsulating a structural cementitious core.
CORE Cementitious Compound
TOLERANCE
±0.25mm and a flatness tolerance of ±0.5mm measured on a diagonal across the top of the panel
FINISH
ASP’s standard powder coated finish.
CONNECTION
The panel is screw fixed to the pedestal head at all
four corners
Moulded Galvanised Steel Top Plate
Moulded Galvanised Steel Bottom Plate
Calcium Sulphate Core
Load tolerances
